| Ascend speed |
9- 10 m/min |
| Whole Machine Weight |
1928 Kg (Steel) 1814 Kg (Aluminum) |
| Suspension mechanism from front beam extent |
1.1 m 1.7m (Should reduce the load on suspended platform when extent is 1.5 m or more) |
| Suspension mechanism Weight |
2 x 175 Kg |
| Suspension mechanism Height adjustment |
1.15 m 1.75m |
| Suspended platform weight |
538 Kg (Steel) 424 Kg (Aluminum) |
| Suspended Platform size L x W x H |
(2500x 3) x 760 x 1450mm |
| Safety Lock Type |
Tilt Proof Safety Lock |
| Rated Load |
800Kgs |
| Minimum Breaking force |
65.5 kN |
| Hoist Related Lifting Force |
8 kN |
| Hoist Model |
LTD 80 |
| Electric Motor Voltage |
AC 380V, 3-Phases (AC415V, 3-Phases ) |
| Electric Motor Type |
YEJ100L1-4 |
| Electric Motor Power |
2.2 kW |
| Electric Motor Braking Torque |
15N x m |
| Balance Weight |
1000 Kg |
